Genelec 1032C SAM Two-way Monitor System

Genelec 1032C

The 1032C is a high-SPL nearfield monitor that fuses the much-loved soffit-mountable styling of the iconic 1000 series with our latest Smart Active Monitoring technology.

Key Technologies

• Active Crossovers
• Directivity Control Waveguide (DCW™) Technology
• Optimised Amplifiers
• Protection Circuitry
• Room Response Compensation
• Smart Active Monitor (SAM™) Systems
• Intelligent Signal Sensing (ISS™) Technology

Even higher performance

Retaining all the revered audio characteristics of the previous A and B versions, the 1032C now features digital connectivity, a universal power supply and powerful Class D amplification; enabling it to produce higher SPL and greater low frequency extension than its already powerful predecessors.

A smart classic

In addition to its trademark out-of-the-box neutrality, the 1032C now integrates closely with our GLM software via which it can be configured and calibrated for your listening environment, compensating for detrimental room influences to create a truly optimised monitoring solution. This makes the 1032C is the perfect choice for professionals in high-end music production, post production and broadcast whose mixes need to translate perfectly to other rooms and systems.

SPECIFICATIONS

• Frequency Response: 40 Hz – 20 kHz (± 2.5 dB)
• Low cutoff -6dB: 33 Hz
• High cutoff -6dB: 23 kHz
• Peak SPL: ≥124 dB
• Short term max SPL: ≥114 dB
• Long term max SPL: ≥104 dB
• Self-generated noise: ≤5 dB SPL
• Height: 495 mm (19 1/2 in)
• Width: 320 mm (12 19/32 in)
• Depth: 290 mm (11 13/32 in)
• Weight: 17 kg (37.5 lb)
• Enclosure material: MDF
• Bass Driver type: Cone Magnetically shielded bass driver.
• Bass Diameter: 250 mm (9 27/32 in)
• Treble Driver type: Metal dome Magnetically shielded treble driver.
• Treble Diameter: 25 mm (31/32 in)
• Harmonic distortion: 50…200 Hz ≤1 %, > 100 Hz ≤0.5 %
• 8340A bass amplifier: 250 W Class D
• 8340A treble amplifier: 150 W Class D
• Mains voltage: 100-240 VAC 50/60Hz
• ISS Active: ≤1 W
• Idle: ≤11 W
• Full output: 200 W
• Input: Analog signal input connector XLR female, balanced 10 kOhm.
• Output: Digital signal output / Thru connector XLR male 110 Ohm.
• 2 x Control: Two CAT5 (RJ45) GLM Network connectors for computer control using the Genelec Loudspeaker Manager (GLM) software.
